Caractéristiques

High-Torque Power for Heavy Pulling

The TB1004 provides the torque reserve and traction required for heavier agricultural applications. Its 100HP power platform is suited to demanding tillage, towing, transport, and large-implement operations where sustained pulling performance is important.

12F+12R Shuttle Transmission for Better Power Matching

The 12F+12R shuttle transmission provides a broad selection of working speeds while making directional changes easier. The practical speed matching allows operators to keep the engine and implement working conditions better coordinated across different field tasks, helping convert available engine power into productive work.

Independent Controls for Smoother Implement Operation

The independent clutch arrangement makes gear shifting and PTO engagement more convenient when connecting or operating agricultural implements. Full hydraulic steering and side-mounted controls further reduce operating effort, giving the operator more direct control over tractor movement and implement-related tasks.

Practical Details for Longer Working Seasons

The redesigned hood improves access for cleaning and maintenance while promoting engine-compartment ventilation. Enhanced front headlights provide better visibility for early-morning or evening operations, allowing the TB1004 to remain productive when agricultural schedules extend beyond normal daylight hours.

CARACTÉRISTIQUES

Drive Type	—	4×4
Rated Power	kW	74
Overall Dimensions (L × W × H)	mm	3945 × 1860 × 2730
Wheelbase	mm	2110
Minimum Ground Clearance	mm	350
Minimum Operating Mass	kg	3000
Front Tread	mm	1400 (1200–1600), Adjustable
Rear Tread	mm	1400 (1300–1600), Adjustable
Clutch Type	—	Dry-Type, Double-Acting
Engine	—	4-Cylinder
Rated Speed	r/min	2400
Gear / Transmission	—	12F + 12R
PTO Type	—	Same
PTO Rated Power	kW	≥63
PTO Speed	r/min	540/720; 540/1000
Three-Point Linkage	—	Rear, 3-Point Suspension, CAT II
Hydraulic Output	—	2-Way Valve
Hydraulic Adjustment Mode	—	Same
Maximum Lifting Force at 610 mm Frame Center	kN	≥20.2
Standard Tire Size (Front/Rear)	—	8.3-24 / 14.9-30
Optional Tire I	—	9.5-24 / 16.9-30
Optional Tire II	—	8.3-20 / 12.4-28
Heated Cabin	—	Optional
ROPS	—	Optional
ROPS with Sunroof	—	Optional
