High-Power Performance for Heavy-Duty Farming

Designed for demanding agricultural applications, the TD1404 delivers 140HP of powerful performance with excellent torque reserve. Equipped with Dongfanghong electronically controlled unit pump or high-pressure common rail engine technology, it provides strong pulling force, efficient fuel consumption, and reliable operation under heavy loads. The optional multi-mode power control switch enables flexible power management for different working conditions, helping maximize efficiency and reduce operating costs.

Engineered for Maximum Strength and Durability

The TD1404 features a reinforced TD chassis, heavy-duty four-wheel-drive system, and a proven front drive axle with high torque transmission capability, providing outstanding stability and traction in challenging field environments. The imported high-strength powder metallurgy clutch disc enhances power transfer reliability, while KA pre-filter and Donaldson air filter systems provide superior filtration performance and easier maintenance.

Built for Continuous Field Productivity

With a 24-speed transmission offering 16 forward and 8 reverse gears, the TD1404 provides precise speed selection for plowing, transportation, and other agricultural operations. The standard creeper gear expands low-speed working capability, while the 200L high-capacity fuel tank supports extended operation with fewer interruptions. The 540/1000 rpm PTO allows efficient matching with a wide range of implements.

Premium Cab Designed Around the Operator

The TD1404 is equipped with a luxury cab featuring soft interior trim, radio, and heating & cooling air conditioning, creating a comfortable working environment in all seasons. The intelligent instrument panel with fault code display allows operators to monitor machine conditions quickly, improving convenience, safety, and maintenance efficiency.

CARACTÉRISTIQUES

Drive Type	—	4WD
Overall Dimensions – Length	mm	4675
Overall Dimensions – Width	mm	2170
Overall Dimensions – Height	mm	3040
Wheelbase	mm	2449
Front Wheel Tread	mm	1730
Rear Wheel Tread	mm	1620
Minimum Ground Clearance	mm	425
Minimum Service Weight	kg	4720
Transmission	—	16F + 8R
Travel Speed – Forward	km/h	1.82–33.34
Travel Speed – Reverse	km/h	2.7–24.07
Steering System	—	Fully Hydraulic, Front-Wheel Steering
Engine Model	—	LR6M3ZU22/1030E
Rated Power	kW	103
Rated Speed	rpm	2200
Front Tire Size	—	13.6-24
Rear Tire Size	—	16.9-34
Maximum Lifting Force	kN	≥19.5
Hydraulic Control Modes	—	Height Adjustment, Floating Control
Maximum Traction Force	kN	29.5
PTO Type	—	Rear-Mounted, Semi-Independent or Independent
PTO Speed	rpm	540 / 1000
PTO Power	kW	83.2
Front Counterweight	kg	270
Rear Counterweight	kg	320
